Mini loader ( HQ915 )
Model No.︰HQ915
Brand Name︰HQ
Country of Origin︰China
Unit Price︰US $ 10690 / pc
Minimum Order︰1 pc
Product Description
Wheel Loader HQ915 Product Description
CE Certificate
Euro iii Engine
Multi-function
Joystick operation
Quick Hitch
Specifications of HQ915 wheel loader
1, Overall Dimensions : 4850mmx1650mmx2727mm
2, Operating Weight: 4700kg
3, Max. Breakout Force: 45KN
4, Max. gradeability : 30 degree
5, Engine Details :
(1) Model: Xinchai Euro 3 A498BT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g/kw. H
6, Transmission System :
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
(1) Model: Xinchai Euro 3 A498BT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g/kw. H
6, Transmission System :
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
7, Operating Specifications :
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4200mm
(3) Driving System: Hydraulic torque converter
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4200mm
(3) Driving System: Hydraulic torque converter
8, Brake System :
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
9, Bucket :
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 1700mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Rated Load: 1500kg
10, Tyre
(1) Model: 12-16.5 / 14-17.5
8.0 Wheelbase: 2000mm
9.0 Track: 1600mm.
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
9, Bucket :
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 1700mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Rated Load: 1500kg
10, Tyre
(1) Model: 12-16.5 / 14-17.5
8.0 Wheelbase: 2000mm
9.0 Track: 1600mm.
Payment Terms︰ T/T
Product Image
